Full Automatically Jerry Can Moulding Machine ABLD90 Screw Diameter 90mm

Large Image : Full Automatically Jerry Can Moulding Machine ABLD90 Screw Diameter 90mm

Product Details:

Place of Origin:	JIANGSU, CHINA
Brand Name:	ABC
Certification:	CE/SGS

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	Negotiable
Packaging Details:	Film packing/Carton packing/Wooden packing
Delivery Time:	40 working days
Payment Terms:	L/C, T/T
Supply Ability:	20 sets per month

Contact Now

Detailed Product Description

Max. Product Volume:	60 Liters	Dry Cycle:	300pc/h
Screw Diameter:	90mm	Screw L/D Ratio:	25 L/D
Screw Drive Power:	37 KW	Screw Heating Capacity:	18 KW
Highlight:	water bottle moulding machine , auto blow moulding machine

Full automatic jerry can blow molding machine ABLD90

Brand: ABC
Code: 8477309000

Product Description

Max. Product volume	60 liters
Dry cycle	300pc/h
Screw diameter	90mm
Screw L/D ratio	25 L/D
Screw drive power	37 KW
Screw heating capacity	18 KW
No.of heating zone	4 zones
Output of HDPE	150 KG/H
Servo oil pump drive power	18.5 KW
Clamping force	320 KN
Template size	900*900mm
Max.size of mold	700X1050mm
Mold stroke	550-1200mm
Max.die diameter	340mm
Die heating power	18 KW
Die heating segments	4 zones
Blowing pressure	0.8mpa
Air volume	1.0 M/MIN
Cooling water pressure	0.3mpa
Water consumption	90 L/MIN
Size of machine	5.22.94.6
Weight of machine	13.5ton
