Detail Information

Condition:	New	Application:	Bottle,water Tank,container,medical,road Barrel
After-sales Service Provided:	Engineers Available To Service Machinery Overseas,Online Support,Video Technical Support,Field Installation,commissioning And Training	Plastic Processed:	PET,PE,PP,HDPE,ABS
Automatic:	Yes,No	Blow Moulding Type:	Stretch Blow Moulding,Extrusion Blow Moulding,Injection Blow Moulding
Color:	White(can Be Customized),Blue,Customized,Yellow,Green	Use:	Making PET Bottle,water Bottle,food,pharmaceutical Field,cosmetic
Machine Type:	High Speed Plastic Bottle Making Machine,Semi-automatic Bblowing Machine,Hydraulic Driven,Extrusion Blow Molding Machine,bottle Forming Machine	Key Words:	Blow Molding Machine,machine,PET Stretch Bottle Blowing Molding Machine
Highlight:	full automatic pallet blow molding machine , high speed pallet blow molding machine , high speed plastic blow molding machine

Product Description

XHD1000L Full-Automatic Plastic Blow Molding Machine – Credible Factory Direct Source

Product Introduction

Offered in two variants—the single-screw XHD1000FZ and double-screw XHD1000FZ—the XHD1000L Fully Automatic Plastic Blow Molding Machine is custom-engineered for float manufacturing. It features HDPE/HMW-HDPE as its primary raw materials, and excels with a fully automated operational process, remarkable production capacity, and material usage that cuts down on costs effectively. Certified by CE and SGS, this machine comes with value-added perks including on-site installation, equipment commissioning, and complimentary professional training sessions. In addition, we provide a 1-year warranty coverage for the entire unit as well as its paired molds.

Tabular Parameters

1. Working Conditions

Working Conditions	Specific Requirements
Worksite Environment	Indoor workshop area with sufficient ventilation; overhead crane system with a minimum vertical height of 9m; factory ground foundation with a required concrete thickness of 10cm and above; mandatory placement in zones free of magnetic field interference; ambient humidity restricted to ≤90%; working temperature range of 0–45℃
Electrical Supply	Three-phase four-wire power system; frequency fixed at 50Hz; voltage tolerance range of 380V–415V
Cooling Water System	Cooling water inlet temperature shall not exceed 20℃; water supply pressure is required to be ≥0.3Mpa; continuous water consumption stands at 50 tons per hour.
Compressed Air Source	Air source pressure 0.8Mpa; air pressure for product forming 0.2-0.4Mpa
Recommended Raw Materials	High-density polyethylene (HDPE) or high-molecular-weight high-density polyethylene (HMW-HDPE)

2. Equipment Overview

No.	Item	Single Screw Configuration	Double Screw Configuration
1	Extruder	140MM, L/D ratio 30:1	120/120MM, L/D ratio 30:1
2	Machine Die Head	35L 26KGS, high-efficiency ceramic heating ring	35L 26KGS, high-efficiency ceramic heating ring
3	Clamping Unit	3-piece type clamping unit with 2 pull bars, clamping force 1000KN	3-piece type clamping unit with 2 pull bars, clamping force 1000KN
4	Machine Frame	Elevating machine frame	Elevating machine frame
5	Material Loader	Spring-type feeding machine (2.2KW)	Spring-type feeding machine (2.2KW)
6	Blow Seat	Multi-function blow seat (5 functions: air blowing/exhausting, sealing, etc.)	Multi-function blow seat (5 functions: air blowing/exhausting, sealing, etc.)
7	Robot	Adjustable 4-function robot (forward/backward movement, cooling, etc.)	Adjustable 4-function robot (forward/backward movement, cooling, etc.)
8	Hydraulic System	Taiwan Delta servo-controlled main hydraulic station + wall thickness control small hydraulic station	Taiwan Delta servo-controlled main hydraulic station + wall thickness control small hydraulic station
9	Electrical System	Siemens PLC/Italy Gefran control system (optional)	Siemens PLC/Italy Gefran control system (optional)
10	Machine Power	Total power 252.375KW, average power 134KW	Total power 346KW, average power 176KW
11	Machine Dimension (L×W×H)	8×4×6.3M	8×4×6.3M
12	Machine Weight	25TON	30TON
13	Melting Capacity	280KGS	280KGS
14	Product Layers	1 layer	1 layer

3. Core Components Material & Configuration

Components	Material/Configuration
Screw/Barrel	38CrMoAl
Die Pin/Core Pin	45# steel
Accumulator	38CrMoAl & 45# steel (35L/26KGS)
Hydraulic Components	Taiwan Yuken pumps and valves
Pneumatic Components	STNC & AirTac pneumatic valves
Low-Voltage Apparatus	Siemens (contactors, circuit breakers, etc.)
Wall Thickness Control System	Japan MOOG 200-point axial wall thickness controller
Servo System	Delta servo motor, Italy PHASE servo control, Japan Sumitomo servo oil pump

Product Core Functions

1.Material Processing The IKV-designed screw achieves high-efficiency plastic melting and uniform material mixing, with a maximum melting capacity of 280KGS.

2.Molding Control Fitted with a Moog 200-point wall thickness controller, the machine ensures consistent wall thickness for finished products and allows flexible weight adjustments over a wide range.

3.Automatic Operation A dedicated industrial robot is responsible for automatic product unloading. The 5-in-1 blowing station combines air blowing, pressure release, sealing and other key processes, achieving a fully automated production process.

4.Temperature Control Utilizing a peak-shifting step heating method, the system is equipped with independent temperature adjustment for both the die head and screw, effectively reducing overall energy consumption.

5.Easy Maintenance The independent pneumatic unit and integrated manifold configuration enable convenient inspection and operation, with all pipelines arranged in an orderly and unobstructed way.

Product Competitive Advantages

1.Cost-Effective Operation In comparison to rotational molding tanks, raw material consumption is cut down by 25%-35%; the built-in frequency conversion control system helps reduce power consumption efficiently.

2.Enhanced Production Efficiency Delivers higher output than rotational molding equipment; the whole production line only requires 3-4 operators, and a single machine can be operated by 2 female workers.

3.Outstanding Product Performance The end products exhibit much better impact resistance than rotational molding tanks, coupled with superior thickness uniformity.

4.Stable & Reliable Configuration Adopts components from well-known brands such as Siemens, Delta and MOOG, ensuring excellent operational stability during long-term use.

5.Comprehensive Service Assurance Provides free installation and training, comes with a 1-year warranty period, and offers free replacement parts for fault repair and maintenance.

Product Distinctive Features

1. Rational Structural Design

Boasts an elevated machine frame and a backplate designed with multi-row threaded holes; hydraulic-driven mold change with a 1600MM moving stroke ensures effortless operation, rendering the equipment suitable for manufacturing a diverse range of float products.

2. High-Precision Control System

Integrated with Taiwan Delta servo hydraulic system, delivering ultra-fast response and pressure rising performance while cutting energy consumption by more than 40%; PLC-based automatic temperature control is implemented, paired with a multilingual operational interface (customizable to include the client’s native language for ease of use).

3. Premium & Durable Materials

Key components are crafted from high-quality alloy and carbon steels including 38CrMoAl and 45# steel; cast steel lifters and Schneider solid-state relays are employed, with AC contactors specifically configured for high-temperature working zones to match operational demands.

4. Safe & Stable Operation

Equipped with full-set machine protective enclosures and safety guardrails for operational security; the cooling system is built with dual protection mechanisms (barrel air cooling + feeding zone water cooling), allowing the machine to operate stably in indoor environments with a temperature range of 0-45℃.

Application Scenarios

Custom-engineered for the production of float products, this machinery is perfectly suited for the mass manufacturing of HDPE float components—such as marine buoys, shipborne floats and floating accessories for water platforms—and is widely utilized in aquaculture industry, offshore engineering undertakings and marine vessel auxiliary equipment fields.

High Speed Full Automatic Pallet Blow Molding Machine XHD1000L 1

High Speed Full Automatic Pallet Blow Molding Machine XHD1000L 2
