Automatic HDPE Blow Moulding Machine For Child Car Seat 8 Liters 8KW

Automatic HDPE Blow Moulding Machine For Child Car Seat 8 Liters 8KW
Automatic HDPE Blow Moulding Machine For Child Car Seat 8 Liters 8KW

Large Image :  Automatic HDPE Blow Moulding Machine For Child Car Seat 8 Liters 8KW

Product Details:
Place of Origin: JIANGSU, CHINA
Brand Name: ABC
Certification: CE/SGS
Model Number: ABLB75II
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Film packing/Carton packing/Wooden packing
Delivery Time: 30 working days
Payment Terms: L/C, T/T
Supply Ability: 20 sets per month
Detailed Product Description
Product Name: 1L, 2L Oil HDPE Bottle Plasitc Extrusion Automatic Blow Molding Machine Material: HDPE
Color: Blue Automatic: Yes
Station: Double Weight: 7.5Ton
High Light:

HDPE Automatic Blow Moulding Machine

,

8 liters HDPE Blow Moulding Machine

,

8KW HDPE Blow Moulding Machine

HDPE Automatic Blow Moulding Machine For Child Car Seat Blow Molding Machine



This machine is suitable for 5~8L product and it is bottom blow.The die-head is accumulator.It equipped with servo motor.The platen of this machine is bigger than the standard 160L machine. The main parts of this machine are designed and manufactured by ourself.We do the independent R&D and inspection.If you have other special requirements,we can provide customized services for you.



1) High pressure& speed injection system

2) V.D pump control for more energy saving

3) Jinhua control system for high speed information communication and high precision temperature control

4) Hot-runner injection-blow mold with horizontal three positions for continuous production with no leftovers or waste material

5) Top brand electric parts and hydraulic parts for long service life

6) High speed: cycle time only 10.5sec for 40ml bottle mould in 14 cavities which is suitable for high quantity production.

7) Bottle size: 3 to 1000mL .

8) 10mL, Cav-9, 100mL, Cav-4.

9) Materials: PP, PE, PS, SAN. EVA.





Max. Product volume8 8 liters
Screw diameter 75mm
Screw L/D ratio 24 L/D
Screw drive power 22KW
Screw heating capacity 7-8KW
No.of heating zone 4 zones
Output of HDPE 100KG/H
Oil pump drive power 7.5 KW
Clamping force 80KN
Max.size of mold 400x430mm
Mold stroke 170-520mm
Template size 380 X 420mm
Max.die diameter 170mm
Blowing pressure 0.6 mpa
Air Volume 0.8M³/MIN
Cooling water pressure 0.3mpa
Water consumption  80L/MIN
Size of Machine 4.2x2.2x2.7m
Weight of machine 7.5ton

The main components of the machine. ( ABLB75II)

electronic parts
Name Trader
Micro computer control system WIRETECH from TAIWAN/MUTISUBISHI
Temperature Controller WIRETECH from TAIWAN/MUTISUBISHI
Auxiliary Relay OMRON
contactor Schneider from France
Electric motor

Schneider from France

Three phase 380V

Power Source TAIWAN MEANWELL
Transducer ABB from Switzerland
hydraulic parts
Name Trader
Oil pump HIGH-TECH
Valve YUKEN
Sealed part HALLITE
air control system
Name Trader
Cylinder AIRTAC
Air Valve AIRTAC
